About us
GISMA was founded in 1983 with the production of pressure hull penetrators for the defence market.
We have >95% in-house production depth and produce 100% of our designs in-house, allowing for complete control over adjustments, availability and product lifecycles.
We currently have about 110 employees and the size of our facility is 5.800 m² with plans to expand towards the end of this year, based on the increible growth over the past years.
GISMA Steckverbinder GmbH designs and produces high performance underwater connectors that are deployed deep sea down to 10.000 m. The actual production line comprises more than 15.500 different electrical, coaxial, fibre-optical, hybrid connectors and penetrators for Defence, Offshore, Renewables and R&D applications. Connectors are available with up to 265 contacts, suiting to maximum current rating of 1.000 amps and 10.000 V working voltage.
Address
Leinestr. 25
24539 Neumuenster
Germany
E-mail: info@gisma-connectors.de
Phone: +49 4321 9835-30
Internet: gisma-connectors.de
Contact person:
Tobias Frerck
Managing Director
E-mail: info@gisma-connectors.de
Phone: +49 4321 9835-30
Products & Services
Our product range is divided into multiple series, separating form, function and area of use.
Additionally, we create customer bespoke cable- and oil filled hose-sets, for which we offer the termination work and FAT in-house.
Due to the large variety of our connectors, we recommend you send us an inquiry with your technical specification, since not all our products can be showcased in our catalogues. We will gladly help you find the best and most cost efficient solution.
Series 10
The main fields of application are:
- Offshore Industry
- Renewable Energy
- Naval Technology
- Marine Research
The series 10 described in this catalogue is designed for underwater operations down to 10,000 m depth.
Thanks to the very high strength of the locking-screw thread, series 10 is especially suitable for robust and frequent mating operations.
Series 10 connectors can be mated wet or underwater, up to a max. water-depth of 100 m. Except of those with high-voltage inserts size 6 and 7.
All series 10 purely electrical connectors with 1 mm or 1.5 mm contacts can be exposed open-faced to water pressure.
With contact arrangements from 3 - 61, current ratings up to 150 A and voltages up to 6,600 V, the GISMA series 10 comprises a wide range of high performance underwater electrical connectors.
Design features:
- underwater wet mateable (size 1 to 5)
- double sealing system in the mating area (lip sealing, conical sealing), if necessary an additional O-ring in the mating area is available for dry mating and applications up to 100 bar
- shell material: bronze, titanium, stainless steel
- solid metal shell housing
- plug and receptacle insulator are longitudinally and open face watertight
- high performance contacts
- nickel- and gold plated contacts
- scoop proof design
- high pressure watertight
- locking sleeve with flat thread
- huge numbers of contact arrangements are available At series 10 special designs are available on request.
- insulation distance according to DIN EN 60664-1 (VDE 0110-1)
Series 16
The main fields of application are:
- Offshore Industry
- Renewable Energies
- Long Term Applications Subsea
Our series 16 connector design makes it the most robust connector for offshore subsea use on the market.
Design features:
- two API test-ports in the receptacle
- double sealing technology in each sealing level
- unmated longitudinally watertight
- high operating security due to elastomere insulator
- insulator with lip sealing and conical sealing
- robust design
- hose adapter with safety screw
- designed for hose and cable termination technique
- a robust flat threat tolerant against pollution
- shell material titanium
- clamp material titanium
- rubber boot material FVMQ
- O-ring material FKM
- single contact designed for bootseal application
- inverse contact layouts available
- dry mateable, moisture tolerant elastomeric insulator body, for safe mating under rough environmental condition
- insulation distances according to DIN EN 60664-1 (VDE 0110-1)
Series 40
The main fields of application are:
- Offshore Industry
- Renewable Energy
- Naval Technology
- Marine Research
The series 40 is designed for underwater applications down to 6,000 meters depth.
Low insertion loss is attained by direct connection with polished front surfaces of the optical fibres (PC-contact principle).
It is strongly recommended that the termination of the f/o- / hybrid connectors should be carried out by our specialists.
Receptacles can be ordered with pigtails.
For fitting the fibre contacts special tools are required.
Fibre optical and electrical contacts can be replaced by the customer and are available as individual parts.
Please note that for the different contacts suitable O-ring seals must be fitted.
The endbells are removable for maintenance, and give rearside access to the contacts for cleaning and spare fibers (highly recommended) for retermination if needed.
Endbells with strain relief e.g. kevlar armored cable are available on request.
Design features:
- dry mateable
- modular contacts, equippable in each slot (electrical 1mm / electrical 2mm / fibre SM / fibre MM / dummy)
- double O-ring sealing system in the mating area
- interchangeable pressure watertight caps with contact inlay
- electrical, fibre optical and hybrid contact layouts
- shell material: marine bronze, stainless steel and titanium
- dismountable endbell for easy refurbishment
- nickel- and gold plated high performance contacts
- robust keyway
- insulation distance according to DIN EN 60664-1 (VDE 0110-1)
- open face longitudinally watertight
- low attenuation
Series 80
The main fields of application are:
- Subsea Stab Plates
- Subsea Trees
- ROV mateable applications
The fluid filled pressure balanced electrical connector series 80 is specially designed for deep sea mating.
Constant and low mating forces minimize the material stress at all designed pressure and depth capabilities.
The high quality of series 80 is based on a very reliable sealing system, a pressure balanced system and the new GISMA flushing device.
Design features:
- underwater mateable
- constant mating forces at every water depth
- pressure balanced plug
- flushing device for an internal cleaning process during mating
- high performance materials (FVMQ, PEEK, titanium) for long term use
- modular design system
- new maintenance features
- design life time 25 years
- different keyways available
- insulation distance according to DIN EN 60664-1 (VDE 0110-1)
Design features series 80 receptacle:
- longitudinally sealed contact design with 2 independent double O-ring-seals (4 O-rings in total)
- gold plated PEEK isolated beryllium copper pin contact
- shock- and pressure resistant epoxy casting at the receptacle's rear
- receptacles are designed for air and oil-filled junction boxes
- scoop proof design
Series 22
Main fields of application are:
- Naval Technology
- Submarines
- Industrial Applications
The series 22 outboard connectors are specially designed for long-term underwater operations in submarines and other military or civil equipment for depths up to 10,000 m.
The requirements of VG 85519 (pressure hull penetrators for submarines) are fully met. Most of the components have got NATO stock numbers.
To ensure maximum operating safety, series 22 outboard connectors have three independently-operating sealing systems in the mating area (O-ring, lip seal and conical sealing).
Shock and vibration safety is ensured by the metric fine screw-thread in the locking sleeve.
The series 22 range also includes splash- and pressure watertight inboard connectors.
With contact numbers from 1 to 265 and current ratings up to 400 A, series 22 comprises a wide range of applications.
Design features:
- designed for harsh environment conditions
- dry mateable
- tripple sealing system in the mating area (O-ring, lip seal, conical sealing)
- shell material: marine bronze, stainless steel
- solid metal shell housing
- insulators with vulcanised contacts are longitudinally and open face watertight
- locking sleeve with metric fine thread
- huge number of contact arrangements are availabel
- nickel and gold plated high performance contacts
- scoop proof design
- robust keyway
- high pressure resistance
- insulation distance acc. to DIN EN 60664-1 (VDE 0110-1)
- underwater explosion proof components acc. to German naval standards
- shockproof acc. to BV 043
- both side pressure watertight PHP for bidirectional safety
- PHP with triple sealing technology at inboard and outboard mating area available
- special innovative castellated nuts with dismounting protection and sealing wax for simple mounting max. security
- high performance coaxial PHP for up to 18 GHz available
Due to its military nature, the series 22 catalogue is not available for download on our website.
If you are interested in these components, please contact us at info@gisma-connectors.de with your inquiry and we will gladly help out.
Series 35
The main fields of application are:
- Offshore Industry
- Naval Technology
- Marine Research
- Renewable Energy
- Industry Applications
The series 35 miniature connectors with robust metal housing are ideal for harsh environments and underwater applications, also if small design dimensions are required.
Due to the compact dimensions this series is ideal for small sensor housing.
Under advanced environmental condition the longitudinally watertight vulcanised elastomer insulator with insulation cones guarantee high operational reliability. With the double O-ring sealing in the mating area high long-term performance is achieved for different applications.
Special versions for welding installation are available.
The replaceable, twist-protected endbell adapter also enables the connection of special cables to the connector.
Design features:
- available in bronze, stainless steel and titanium
- high pressure watertightness
- double O-ring-sealing in the mating area
- contact arrangement from 3 to 19 contacts
- operating voltage up to 225 V
- operating current up to max. 15 A
- test pressure up to 500 bar
- elastomer insulator with extended conical insulation design
- robust contacts
- open face longitudinally watertight receptacles
- dry mating capability
- safe metric locking thread
- robust keyway
- insulation distance according to DIN EN 60664-1 (VDE 0110-1)
