Main fields of application are:
- Naval Technology
- Submarines
- Industrial Applications

The series 22 outboard connectors are specially designed for long-term underwater operations in submarines and other military or civil equipment for depths up to 10,000 m.

The requirements of VG 85519 (pressure hull penetrators for submarines) are fully met. Most of the components have got NATO stock numbers.
To ensure maximum operating safety, series 22 outboard connectors have three independently-operating sealing systems in the mating area (O-ring, lip seal and conical sealing).
Shock and vibration safety is ensured by the metric fine screw-thread in the locking sleeve.
The series 22 range also includes splash- and pressure watertight inboard connectors.
With contact numbers from 1 to 265 and current ratings up to 400 A, series 22 comprises a wide range of applications.

Design features:
- designed for harsh environment conditions
- dry mateable
- tripple sealing system in the mating area (O-ring, lip seal, conical sealing)
- shell material: marine bronze, stainless steel
- solid metal shell housing
- insulators with vulcanised contacts are longitudinally and open face watertight
- locking sleeve with metric fine thread
- huge number of contact arrangements are availabel
- nickel and gold plated high performance contacts
- scoop proof design
- robust keyway
- high pressure resistance
- insulation distance acc. to DIN EN 60664-1 (VDE 0110-1)
- underwater explosion proof components acc. to German naval standards
- shockproof acc. to BV 043
- both side pressure watertight PHP for bidirectional safety
- PHP with triple sealing technology at inboard and outboard mating area available
- special innovative castellated nuts with dismounting protection and sealing wax for simple mounting max. security
- high performance coaxial PHP for up to 18 GHz available

Due to its military nature, the series 22 catalogue is not available for download on our website.
If you are interested in these components, please contact us at info@gisma-connectors.de with your inquiry and we will gladly help out.
